SS 316 Insulated tank with agitator and double jacket
Capacity: 22000 liter
Year of construction
1999
State
Used
Manufacturer
Van der Moolen
Quantity
1
Capacity size
22,000 liter
Material
SS 316
Working pressure
0 bar
Test pressure
0.03 bar
Foundation
SS legs
Number of legs
3
Modell bottom head
Conical
Modell top head
Conical
Insulation thickness
120 mm
Insulation material
Glass wool
Insulation clad
SS clad
Cylinder
Yes
Bottom head
Yes
Top head
Yes
Brand
Jongia
Type
LD 50
Kind
Propeller
Diameter propeller
820 mm
Number of agitators
1
Location drive
On top
Speed
1420/55 rpm
Engine power
1.5 kW
Inside diameter
2,920 mm
Outside diameter
3,200 mm
Cylindrical height
3,500 mm
Total height
5,850 mm
Leg length
1,100 mm
Outlet height
800 mm
Outlet
70 mm
Inlet
60 mm
Breather vent
100 mm
Type of breather vent
With cap
CIP connection
65 mm
Type of CIP
Rotating
Manhole
500 mm
Place manhole
On top
Type of shell
Thermplate
Heated surface
43 m2
Working pressure steam
2 bar
Working pressure water
2 bar
Max. temp. shell
100 °C
