SS 316 heatable pressure tank with agitator
Capacity: 12000 litre
Year of construction
2021
State
Used
Manufacturer
GPI
Quantity
2
Capacity size
12,000 liter
Material
SS 316
Empty weight
1,600 kg
Working pressure
-0.005/+0.5 bar
Foundation
SS legs
Number of legs
3
Modell bottom head
Round
Modell top head
Round
Insulation thickness
80 mm
Insulation material
Other
Insulation clad
SS clad
Cylinder
Yes
Bottom head
Yes
Top head
No
Kind
Propeller
Number of agitators
1
Location drive
On top
Inside diameter
2,100 mm
Outside diameter
2,262 mm
Cylindrical height
3,300 mm
Total height
6,865 mm
Leg length
1,300 mm
Outlet height
1,275 mm
Outlet
104 mm
CIP connection
DN 100 mm
Manhole
523 mm
Place manhole
On top
Type of shell
Noppenmantel
Heated surface
20.3 m2
Working pressure water
-0/+5 bar
Test pressure
8 bar
Max. temp. shell
0/90 °C
Handelsbedrijf Koster is an internationally active company that buys and sells used SS tanks and machines for the foodstuffs and chemicals industries. We have a large storage site where we always have around 600 tanks in stock. We also have a modern workshop where we can adapt tanks to the requirements of the customer.
